PylonTech US Series
PylonTech Energy Storage Solutions
PylonTech is the globally renowned, industry leading name in Energy Storage Systems. Combining all their knowledge and experience with Lithium LFP technology is the acclaimed US Series. This comprises three model sizes that can be combined to build the system you require. These rackable units provide the perfect answer, whatever your ESS System demands.
US2000C |
US3000 |
US5000 |
|
| Nominal Voltage (Vdc) | 48 | 48 | 48 |
| Nominal Capacity(kWh) | 2.4 | 3.55 | 4.8 |
| Usable Capacity(kWh) | 2.28 | 3.37 | 4.56 |
| Dimension(mm) | 442*410*89 | 442*410*132 | 442*420*161 |
| Weight(kg) | 22.5 | 32 | 39.7 |
Why choose Pylontech?
Safety
Multi-protection from self developed BMS.
Optimal Electricity Cost
Long cycle life and superior performance.
Compact Size & Easy installation
Module design help for quick installation
Easy to Scale Up
Be workable to be parallel based on 48V.
Compatibility
Compatible with Tier 1 inverter brands.
Residential BESS
Save costs and save the planet, with PylonTech battery storage solutions.
Benefits from Peak Shaving
Energy demand is highest in the mornings and evenings. Store the electricity during the low-peak times and use the energy at peak-time. This saves you money and keeps you independent from the grid.
VPP Revenue
VPP creates a network of renewable energy sources and battery storage systems, connected through a cloud-based technology. Managing the stability of clean electricity to maximise your revenue.
This will enable a reduction in costs and boost the system’s efficiency.
Powercube-M2A-180 |
Powercube-M3A-100 |
Powercube-M3A-100 |
|
| 729.6V148Ah | 729.6V148Ah | 1113.6V148Ah | |
| Battery System Capacity(kWh) | 107.98 | 107.98 | 164.81 |
| Battery System Voltage(Vdc) | 729.6 | 729.6 | 1113.6 |
| System Voltage Range(Vdc) | 615.6-820.8 | 615.6~820.8 | 939.6~1252.8 |
| Efficiency | 96% | 96% | 96% |
| Depth of Discharge | 90% | 90% | 90% |
| Dimension (W*D*H, mm) |
803*855*2130 | 800*855*2130 | 1185*855*2130 |
| Weight (Kg) | 1228 | 1228 | 1798 |
Downloads
